Type Hermetic reciprocating
COOLING CAPACITY 1318 W (HBP)
Technology Type On-Off
Displacement 14.28 cm³
Compressor Cooling Fan/NotControled/220
Fan Air Flow 520 m³/h
Expansion Device Capillary Tube or Expansion Valve
Horse Power 1/2 hp
Max Condensing Pressure Operating 13.92 bar
Max Condensing Pressure Peak 15.62 bar
Power Supply 220-240 V 50 Hz
Evaporating Temperature Range -15 °C to 10 °C
Motor type CSIR
Starting Torque HST
Start Winding Resistance 27.95 at 25° C
Run Winding Resistance 5.11 at 25° C
Maximum Recommended Refrigerant Charge 350 g
Oil Charge 350 ml
Oil Type Configuration ESTER
Oil Type Viscosity ISO22
Pressurization Dry air charge
Weight 11.2 Kg
Free Internal Volume 2.1 L
Start Capacitor 72-88 Uf / 330 V
Starting Device Relay | MTRP-0012*
Motor Protection T0741/G6
COOLING CAPACITY 1318 W (HBP)
Technology Type On-Off
Displacement 14.28 cm³
Compressor Cooling Fan/NotControled/220
Fan Air Flow 520 m³/h
Expansion Device Capillary Tube or Expansion Valve
Horse Power 1/2 hp
Max Condensing Pressure Operating 13.92 bar
Max Condensing Pressure Peak 15.62 bar
Power Supply 220-240 V 50 Hz
Evaporating Temperature Range -15 °C to 10 °C
Motor type CSIR
Starting Torque HST
Start Winding Resistance 27.95 at 25° C
Run Winding Resistance 5.11 at 25° C
Maximum Recommended Refrigerant Charge 350 g
Oil Charge 350 ml
Oil Type Configuration ESTER
Oil Type Viscosity ISO22
Pressurization Dry air charge
Weight 11.2 Kg
Free Internal Volume 2.1 L
Start Capacitor 72-88 Uf / 330 V
Starting Device Relay | MTRP-0012*
Motor Protection T0741/G6
